Name: High Quality Single Phase Automatic Voltage Stabilizer 10KVA AC Power Stabilizer with Good Price
Brand: Ewen (Shanghai) Electrical Equipment Co., Ltd
SKU: TND(SVC)-10KVA
Price: Negotiable USD
Availability: InStock

Home > Products > AC Power Stabilizer >

High Quality Single Phase Automatic Voltage Stabilizer 10KVA AC Power Stabilizer with Good Price

Place of Origin:

Shanghai, China

Brand Name:

Ewen Power

Certification:

CE, ISO: 9001

Model Number:

TND(SVC)-10KVA

Request A Quote

High Quality Single Phase Automatic Voltage Stabilizer 10KVA AC Power Stabilizer with Good Price

Product Details

Name:

Single Phase AC Power Stabilizer

Rated Capacity:

10KVA (can Be Customized)

Series:

TND (SVC)

Input Voltage:

176V-264V (based On Needs)

Output Voltage:

220V/110V (based On Needs)

Working Frequency:

50Hz~60Hz

Output Precision:

Insulation Class:

Waveform Distortion:

Nil

Working Temperature:

-10℃~45℃

Working Humidity:

30%~80%

Protection Class:

IP23

Cooling Method:

Dry Type Air Cooling

Insulation Resistance:

≥5MΩ

Display:

LCD Display

Warranty:

12 Months

Color:

Black, Grey, Or Customized

Package:

Export Packing Plywood Pallet Or Case

Weight:

28kg (estimated)

Material:

Copper Wire

Size:

24x41x37cm

Usage:

To Stabilize The Output Voltage Automatically

Application Field:

Power Sector, Industrial Automation, Robots, Aerospace, Medical Equipment, Communication Systems, New Energy Power Generation, CNC Machines

Payment & Shipping Terms

Minimum Order Quantity

1 pc

Price

Negotiation based on technical requirement and order quantity

Packaging Details

Exporting plywood case for each stabilizer

Delivery Time

According to Quantity, normally 7 days for production

Payment Terms

T/T, L/C

Supply Ability

1000 units per month

380V 400V 415V AC Power Stabilizer Automatic Voltage Regulator 100KVA 3 Phase Servo Motor Type for Industrial Use

Get Best Price

High Quality Single Phase Automatic Voltage Stabilizer 10KVA AC Power Stabilizer with Good Price

Get Best Price

5KVA Automatic Voltage Stabilizer 220V Single Phase AC Power Stabilizer TND(SVC)-5000VA

Get Best Price

Video

SBW-F-2500KVA 50-60 Hz AC Three Phase Full Auto Servo Motor Type Voltage Regulator

Get Best Price

+86 18217375508

helen@ewenpower.com

86-021-69519095

Contact Now

Product Description

Product Name: High Quality Single Phase Automatic Voltage Stabilizer 10KVA AC Power Stabilizer with Good Price

MAIN PARTS:

contact copper regultaion coil,
servo motor,
automatic control circuit,
carbon brush,
other essential parts.

High Quality Single Phase Automatic Voltage Stabilizer 10KVA AC Power Stabilizer with Good Price 2

WORKING THEORY:

when the grid voltage fluctuates,
the sampling control circuit gives out a signal to drive the servo motor,
then the servo motor drives the carbon brush to move along the surface of the copper coil.
through the movement of the carbon brush, the voltage is regulated to 220V or 110V or any voltage that you need.

PROTECTION FUNCTION:

over-voltage
under-voltage
over-current
over-load
time delay

PRODUCT ADVANTAGES

Capacity	Full capacity
Loss	Low loss
Response	Fast response
Performance	Reliable performance
Accuracy	High accuracy
Range	Wide input voltage range

APPLICATION

(1) AC single-phase voltage regulator can be used to regulate the voltage of household appliances, so that household appliances can operate normally,
(2) AC single-phase voltage regulator can be used to regulate the voltage of industrial equipment, so that it can operate normally within a certain voltage range, so as to improve the operation efficiency of industrial equipment
(3) The AC single-phase voltage regulator can be used to adjust the power supply current and control the current output of the power supply, so as to avoid the larger current from flowing into the circuit, so as to achieve the purpose of protecting the electrical equipment.

TND 50Hz / 60Hz 10KVA Single Phase Voltage Stabilizers are mainly used in the following fields: Power sector, Industrial Automation, Robots, Aerospace, Medical Equipment, Communication systems, New Energy Power Generation, CNC Machines.

OUR FACTORY INTRODUCTION

We are a manufacturer:

Ewen (Shanghai) Electrical Equipment Co., Ltd.

Located in Jiading District, Shanghai, P.R.China
We are both a manufacturer and trading company
Specializing in low-voltage electrical equipment.
Main products: voltage transformer, voltage stabilizer, AC DC switching power supply, reactor, and inverter etc.
With rich experience in the industry of electrical equipment.
With strong R&D team, production team, QC team, strong service team,
With advanced manufacturing equipment and testing device.
With business partners in North America, Europe, Africa, East Asia, and Middle East etc.
Ewen offers you technical support, sampling, mass production, OEM&ODM, and after-sale services etc.

We have spared goods for normal products and could customize products for customers. We have a strong and high-efficient R&D team to design products according to your requirements. Besides, we could offer products on time and provide you with comprehensive services. We will be a right supplier with whom you could cooperate for a long time.

High Quality Single Phase Automatic Voltage Stabilizer 10KVA AC Power Stabilizer with Good Price 5

Please contact us at:

EWEN (SHANGHAI) ELECTRICAL EQUIPMENT CO., LTD.

Mobile/WeChat/WhatsApp: +86 182 1737 5508

Email: helen@ewenpower.com
